Bracket 20*20 with cap for profile series 5 2020

Name: Bracket 20*20 with cap for profile series 5 2020
Brand: DHM
SKU: 14030110
Price: 4.79 EUR
Availability: InStock

Reference: 14030110

€4.79

VAT included Shipping excluded

Immediate Availability

Dispatch in 24/48H

Product Details
Brand DHM
Reference 14030110
-- Stocks: Immediate Availability *

*Regular shipments throughout Europe
Description
Package contains: 1 x Bracket with cap for profile serie 5 2020

Aluminum profiles can be connected to each other by means of a bracket. This connection involves the insertion of nuts in the slots of the profiles and fixing with screws. The bracket in question is a 90° model with side fins that prevent possible rotation. The characteristic of the brackets with fins is that the protrusions to be inserted in the slots allow the simple pressure of the nuts on these to keep them in position. They are characterized by slotted holes to allow them to be mounted on holes in different positions.
The use of washers is recommended for installation. They allow L or cross connections.
Read more
Specifications in the data sheet inside the image gallery. For further information please contact us.

The object that you will receive may differ in some features from that represented in the picture, depending on the production batch. Despite this, the functionality is maintained.
